overall

colab导入库问题

引用挂载的needle库时, 修改了needle库文件内容后, 还需要重新导入

plan a: 启用autoreload, 设置为模式1: 在每次执行cell前, reload用 %aimport 标记过的模块

%load_ext autoreload
%autoreload 1

%aimport needle

或者plan b: 设置为模式2: 在每次执行cell前, reload所有已导入模块

%load_ext autoreload
%autoreload 2

注: 重复导入可能会造成一些奇怪的bug, 可以尝试重启运行时

• bug例: 重复导入ndl库, 导致isinstance(ndl.Tensor, ndl.autograd.Tensor)结果为False ...非常抽象

Jupyter小技巧

使用clear_output来清空上一条命令

!make -j32
from IPython.display import clear_output

clear_output(wait=True)
!python3 -m pytest -v -s -k "(compact or setitem) and cpu"

Homework1

运算

Broadcast

def broadcast_to(a, shape): broadcast an array to a new shape (1 input, shape - tuple) 广播, 复制张量的某些维度, 使得不同形状的数组进行逐元素运算时更加方便

• 向量加标量：把标量加到每个元素。
• 矩阵加列向量：把列向量加到矩阵每一列。
• 矩阵乘以标量：标量自动扩展到矩阵大小。

广播的梯度计算: 沿着广播的维度sum回去

• 广播的本质是变量复制, 广播后的元素参与了多次的计算, 反向传播时要累加这部分的梯度值

Homework2

初始化方法选择

Linear初始化要选择kaiming_uniform, 否则无法通过测试

L2正则化+动量SGD更新公式

$$\begin{aligned} g_i &= \nabla_\theta f(\theta_i) + \lambda \theta_i\\ u_{t+1}&←βu_i+(1−β)g_i\\ w_{i+1}&←w_i−αu_i \end{aligned}$$

TypeError: Module.__init__() takes 1 positional argument but 2 were given

    def forward(self, x: Tensor) -> Tensor:
        ### BEGIN YOUR SOLUTION
        res = x
        for module in self.modules:
>           res = module(res)
                  ^^^^^^^^^^^
E           TypeError: Module.__init__() takes 1 positional argument but 2 were given

• 这里调用的本应该是forward方法而非init, 说明这里的module是一个类, 那么很可能在定义network时不小心传入的是一个类, 而非对象
• 如nn.ReLU()误写为nn.ReLU
• 类型检查没做好...

AssertionError: float64 float32`

NOTE: The default data type for the tensor is float32. If you want to change the data type, you can do so by setting the dtype parameter in the Tensor constructor. For example, Tensor([1, 2, 3], dtype='float64') will create a tensor with float64 data type. In this homework, make sure any tensor you create has float32 data type to avoid any issues with the autograder.

在optimizer中, 会使用float64的超参数乘以float32的tensor, 最终导致整个值变为float64, 此时重新复制给data, 就会引发AssertionError: float64 float32 注: 此为Tensor类方法中的断言

class Tensor(Value):
    @data.setter
    def data(self, value):
        assert isinstance(value, Tensor)
        assert value.dtype == self.dtype, "%s %s" % (
            value.dtype,
            self.dtype,
        )
        self.cached_data = value.realize_cached_data()

过了! 备注: 训练OOM, 被kill掉了

Homework3

如何直接计算noncompact->compact的映射关系

__global__ void CompactKernel(const scalar_t *a, scalar_t *out, size_t size, CudaVec shape,
                                  CudaVec strides, size_t offset)
    {
      /**
       * The CUDA kernel for the compact opeation.  This should effectively map a single entry in the
       * non-compact input a, to the corresponding item (at location gid) in the compact array out.
       *
       * Args:
       *   a: CUDA pointer to a array
       *   out: CUDA point to out array
       *   size: size of out array
       *   shape: vector of shapes of a and out arrays (of type CudaVec, for past passing to CUDA kernel)
       *   strides: vector of strides of out array
       *   offset: offset of out array
       */
      size_t gid = blockIdx.x * blockDim.x + threadIdx.x;

      /// BEGIN SOLUTION
      // assert(false && "Not Implemented");
      if (gid >= size)
        return;

      size_t a_idx = offset;
      size_t tmp = gid;

   for (size_t i = shape.size; i > 0; i--)
      {
        // 计算当前维度的索引
        size_t dim_idx = tmp % shape.data[i - 1];
        // 计算基于步长的映射, 并累加
        a_idx += dim_idx * strides.data[i - 1];
        tmp /= shape.data[i - 1];
      }
      out[gid] = a[a_idx];
      /// END SOLUTION
    }

Compact & Setitem

void Compact(const AlignedArray &a, AlignedArray *out, std::vector<int32_t> shape, std::vector<int32_t> strides, size_t offset){
/**
* Compact an array in memory
*
* Args:
*   a: *non-compact* representation of the array, given as input
*   out: compact version of the array to be written
*   shape: shapes of each dimension for a and out
*   strides: strides of the *a* array (not out, which has compact strides)
*   offset: offset of the *a* array (not out, which has zero offset, being compact)
*
* Returns:
*  void (you need to modify out directly, rather than returning anything; this is true for all the
*  function will implement here, so we won't repeat this note.)
*/
}

void EwiseSetitem(const AlignedArray &a, AlignedArray *out, std::vector<int32_t> shape, std::vector<int32_t> strides, size_t offset){
/**
* Set items in a (non-compact) array
*
* Args:
*   a: **_compact_** array whose items will be written to out
*   out: non-compact array whose items are to be written
*   shape: shapes of each dimension for a and out
*   strides: strides of the *out* array (not a, which has compact strides)
*   offset: offset of the *out* array (not a, which has zero offset, being compact)
*/
}

• compact将non-compact的a写入到compact的out数组中
• setitem将compact的a写入到non-compact的out数组中 所以两个是一个相反的操作
